Aerospace Equipment

Aerospace tube is a kind of seamless steel pipe with high strength and thick wall. It is widely applied in aerospace equipment. There are different grades of pipes. 10#, 20#, 35# and 45# types are general tubes. 27SiMn, 12Cr1MoV, 10CrMo910, 15CrMo, 35CrMo grades of pipes are alloy steel pipes. 16Mn aerospace tube, different from general steel pipe and alloy steel tube, is called low alloy seamless steel pipe.

Advantages

• JST aerospace tubes are featured with small volume, light weight and small power dissipation. It can work in poor conditions featuring high efficiency, high reliability and long service life.
• We configure advanced thermal treatment equipment with small temperature difference inside the furnace to ensure stable heating temperature. We also provide rotating cooling system for this seamless steel pipe to ensure that water quenching of steel pipe cools uniformly. Two Siemens electronic control six roll straightening machines ensure the straightness of aerospace tubes after heat treatment.

Features

• It is characterized by high strength, uniform and stable structure and performance. This seamless steel pipe uses pure steel (P ≤ 0.020%, S ≤ 0.010%).
• JST aerospace tube features high wall thickness precision and small tolerance range. The unevenness of the same section is equal to or less than 9.5%.
• The control precision of heat treatment furnace temperature is equal to or less than 5℃.
• This seamless steel pipe has low residual press. After heat treatment and high temperature tempering, we adopt hot straightening. The final straightening temperature is controlled to be equal to or more than 450℃.

Technical Parameters of Aerospace Tube Mechanical Properties of Aerospace Seamless Steel Pipe

Grade	Yield Strength (Mpa)	Tensile Strength (Mpa)	Elongation (%)
JST80T/JST80TT	552-758	≥ 689	Calculate according to API 5CT standard formulas.
JST90T/JST90TT	621-724	≥ 689
JST110T/JST110TT	758-965	≥ 862
JST125T/JST125TT	862-1034	≥ 931
JST130/JST130TT	896-1103	≥ 965
JST140T/JST140TT	965-1172	≥ 1034
JST150T	1034-1241	≥ 1103

Established in 1984, Jiangyin Changjiang Steel Tube Making Factory has been engaged in manufacturing seamless steel pipes for about 30 years. We mainly supply aerospace tube, structure pipe, fluid pipe, high pressure boiler pipe, API pipe, marine pipe, alloy pipe, tubing, casing and line pipe for sale. Our products are extensively used in metallurgy, port, ship-breaking, manufacturing, real estate, chemical engineering, transportation and other industries. JST aerospace tubes are well appreciated for their advanced design, sophisticated manufacturing, excellent quality and full service.
