Steel Tube for Bridge Building

Steel Tube for Bridge Building
Inquire Now

Bridge and building often use seamless structural steel pipes. We mainly adopt ASME A519 standard. Representative steel grades include 20#, 45#, Q345-Q460, 40Mn2 and 45Mn2.

Competitive Advantages
  • The surface of steel tube for bridge building is of good quality. There is no visible crack, wrinkling, rolling skin and abscission layer on the inside and outside surface. We can completely remove the flaws and the removal depth is not allowed to exceed the negative deviation of nominal wall thickness. After removal process, the actual wall thickness of this structural steel pipe should not be smaller than the allowable minimum wall thickness deviation.
  • We also have professional inspection personnel who will detect the unobvious inner and outer surface defects on seamless steel tubes. If find any flaw, they will do polishing, removal, repair and a series of processes based on their specific characteristics. These processes are carried out in accordance with relevant standards.
  • After the above treatment, our inspectors will check structural steel pipes again. We also measure the wall thickness to guarantee stable performance of steel tube for bridge building.
Technical Parameters

1. Dimension Deviation of This Seamless Structural Steel Pipe

Type Outside Diameter (D) Wall Thickness (S)
Cold-Drawn Pipe Outside Diameter of Steel Pipe (mm) Allowable Deviation (mm) Wall Thickness of Steel Tube (mm) Allowable Deviation (mm)
＞ 30-50 ± 0.3 ≤ 30 ± 10％
＞ 50-219 ± 0.8％
Hot-Rolled Pipe ＞ 219 ± 1.0％ ＞ 20 ± 10％

2. Mechanical Properties of Steel Tube for Bridge Building

Standard Grade Tensile Strength (Mpa) Yield Strength (Mpa) Elongation (％)
ASTM A53 ASME SA53 A ≥ 330 ≥ 205 Refers to ASTM A53 table and ASME SA53 table.
B ≥ 415 ≥ 240

3. Chemical Composition of This Structural Steel Pipe

Standard Grade Chemical Composition (％)
ASTM A53  ASME SA53   C Si Mn P S Cu Ni Mo Cr V
A ≤ 0.25 / ≤ 0.95 ≤ 0.05 ≤ 0.06 ≤ 0.40 ≤ 0.40 ≤ 0.15 ≤ 0.40 ≤ 0.08
B ≤ 0.30 / ≤ 1.20 ≤ 0.05 ≤ 0.06 ≤ 0.40 ≤ 0.40 ≤ 0.15 ≤ 0.40 ≤ 0.08

Established in 1984, Jiangyin Changjiang Steel Tube Making Factory has been engaged in manufacturing seamless steel pipe for bridge building for about 30 years. We also supply structural steel pipe, fluid pipe, high pressure boiler pipe, API pipe, marine pipe, alloy pipe, tubing, casing, line pipe, etc. Our steel tubes are extensively used in metallurgy, port, ship-breaking, manufacturing, real estate, chemical engineering, transportation and other industries. JST structure steel pipes are well appreciated for their advanced design, sophisticated manufacturing, excellent quality and full service.
