High Pressure Seamless Steel Pipe for Chemical Fertilizer Equipment

High Pressure Seamless Steel Pipe for Chemical Fertilizer Equipment

This steel pipe is applied to the chemical fertilizer equipment for conveying high temperature and high pressure fluid. It is often used in the chemical equipment with the working temperature of -40℃ to 400℃ and with the working pressure of 10 Ma to 30Ma. JST seamless steel tube for chemical fertilizer equipment is made from high-quality carbon structural steel and alloy steel. We adopt hot rolling and cold drawing manufacturing techniques to produce this kind of steel pipe.

Delivery Status We deliver seamless steel tube for chemical fertilizer equipment in the following status:
  • For 20# and 16Mn grades of steel pipes, we deliver them in normalizing state.
  • For 12CrMo grade of pipes, we deliver them in normalizing state (900℃ to 930℃) and tempering state (670℃ to 720℃). The soaking time or duration of time of periodic furnace is two hours while continuous furnace is just one hour.
  • For 12Cr2Mo grade of seamless steel tubes, we deliver them in normalizing state (900℃ to 960℃) and tempering state (700℃ to 750℃). The soaking time is more than one hour.
Parameters of Steel Pipe

1. Allowable Dimension Deviation

Types of Steel Tubes Outer Diameter Wall Thickness
Cold-Rolled Tubes Tube Sizes (mm) Tolerances (mm) Tube Sizes (mm) Tolerances (mm)
>30-50 ± 0.3 ≤ 30 ± 10%
>50-219 ± 0.8%
Hot-Rolled Tubes >219 ± 1.0% > 20 ± 10%

2. Chemical Composition of Steel Tube for Chemical Fertilizer Equipment Parameters

3. Mechanical Properties of Steel Pipe

Grade Tensile Strength (Mpa) Yield Point (Mpa) Min. Elongation (%)

10 335-490 205 24
20 410-550 245 24
16Mn 490-670 320 21
15MnV 510-690 350 19
12CrMo 410-560 205 21

Jiangyin Changjiang Steel Tube Making Factory is a leading supplier and exporter of seamless steel tube for chemical fertilizer equipment. We mainly manufacture structure pipe, fluid pipe, high pressure boiler pipe, API pipe, marine pipe, alloy pipe, tubing, casing, line pipe, etc. Our company sets up a steel tube technology R & D center with advanced pipe testing equipment. Through strict testing process, we are able to produce high quality steel pipes for customers. Our seamless steel tubes have been exported to the Middle East, CIS, Southeast Asia, Africa, South America, North America, Europe, Australia and many other countries and regions.
