Seamless Hot-Rolled Steel Tubes for Hydraulic Pillar Service

Seamless Hot-Rolled Steel Tubes for Hydraulic Pillar Service
Inquire Now

Hydraulic prop tube is made form high-quality carbon structural steel adding one or several types of alloy elements to improve the strength, toughness and hardenability of steel. This hot-rolled seamless steel pipe often needs to go through hardening and tempering, chemical hot treatment, surface hardening and other thermal treatments. Compared to high-quality carbon structural steel, JST hydraulic prop tube owns excellent integrated mechanical properties. We always roll round, square and flat shaped steel products to be used as important structural parts in machinery or machine.

Applications of Hot-Rolled Seamless Steel Pipe Hydraulic prop tube can be used as the cylinder or prop in coal mine hydraulic support and used in other hydraulic cylinders or props. It can be widely applied in hydraulic system, plastic machinery, injection molding machinery, rubber machinery, forging machinery, casting machinery, engineering machinery, automobile industry, shipbuilding industry, metal processing and war industry. This hot-rolled seamless steel pipe can also be used in diesel engine, internal combustion engine, construction machinery, forestry machinery, automation machinery, petrochemical, aerospace, hydraulic pneumatic, air conditioning, shoe-making machinery, etc.

Features of Hydraulic Prop Tube
  • With no oxidation layer on the outside and inside of JST hot-rolled seamless steel pipe, it can withstand high pressure. It also features no leakage, high precision, high fineness and no cold-bending deformation. After flaring and flattening, there is no seam. After surface derusting process, our hydraulic prop tubes acquire good mechanical processing properties.
  • The general length of JST hot-rolled seamless steel pipe is 3000 mm to 12000 mm. The allowable delivery length of each batch of pipes should not be less than 2000 mm, and the weight should not exceed five percent of the ordered pipe weight.
  • Our company configures fixed-length cutting machines. We can cut pipes according to the fixed length provided by customers. This ensures the length accuracy of our hydraulic prop tubes.
  • The two ends of hot-rolled seamless steel pipes can be cut to be perpendicular to the pipe axis. We should remove the burrs on the end surface.

Delivery Status We always deliver our hydraulic prop tubes in hot rolling state. We can also deliver products in annealing or hardening and tempering states according to clients' requirements.

Chemical Composition of Hot-Rolled Seamless Steel Pipe
Grade Chemical Composition (%)
  C Si Mn p S Cr Ni Cu
20 0.17-0.24 0.17-0.37 0.35-0.65 ≤ 0.035 ≤ 0.035 ≤ 0.25 ≤ 0.25 ≤ 0.20
35 0.32-0.40 0.17-0.37 0.50-0.80 ≤ 0.035 ≤ 0.035 ≤ 0.25 ≤ 0.25 ≤ 0.20
45 0.42-0.50 0.17-0.37 0.50-0.80 ≤ 0.035 ≤ 0.035 ≤ 0.25 ≤ 0.25 ≤ 0.20
27SiMn 0.24-0.32 1.10-1.40 1.10-1.40 ≤ 0.035 ≤ 0.035 ≤ 0.25 ≤ 0.25 ≤ 0.30
30MnNbRE 0.27-0.36 0.20-0.60 1.20-1.60 ≤ 0.035 ≤ 0.035 ≤0.25 ≤ 0.25 ≤ 0.30

Jiangyin Changjiang Steel Tube Making Factory is a leading supplier and exporter of hydraulic prop tubes in China. We mainly manufacture structure pipe, fluid pipe, high pressure boiler pipe, API pipe, marine pipe, alloy pipe, tubing, casing, line pipe, etc. Our company sets up a steel tube technology R & D center with advanced pipe testing equipment. Through strict testing process, we are able to produce high quality hot-rolled seamless steel pipes for customers. Our hydraulic prop tubes have been exported to the Middle East, CIS, Southeast Asia, Africa, South America, North America, Europe, Australia and many other countries and regions.
