ASTMA210/ASME SA210 Seamless Steel Boiler and Superheater Tubes

ASTMA210/ASME SA210 Seamless Steel Boiler and Superheater Tubes
Inquire Now

ASTMA210/ASME SA210: Seamless Medium-Carbon Steel Boiler and Superheater Tubes Standard: ASTM A210/ASME SA210
We can provide different grades of carbon steel seamless pipes, such as A210A-1, A210C, and so on.

Introduction ASTMA210/ASME SA210 seamless steel tube for boiler and superheater is a kind of seamless medium-carbon steel pipe with minimum wall thickness. It can be used as boiler pipe, boiler flue pipe (including safe end, vault and support tube) and superheater pipe. This carbon steel seamless pipe is extensively used in boiler, chemical engineering, electric power and other industries. It can also be used in the manufacturing of boiler water wall, economizer, reheater and steam pipes.

Features
  • Heat Treatment
  • JST seamless steel tube for hot-trimming boiler and superheater does not make heat treatment. After the last cold drawing, cold-finished carbon steel seamless pipe will do subcritical annealing, full annealing or normalizing heat treatment. JST has micro-oxidation and non-oxidation furnace with temperature of not exceeding 5℃, which makes the surface of boiler and superheater tube achieve the status of non-oxidation layer and makes the steel surface smooth. The performance of boiler and superheater seamless steel tubes are relatively stable.
  • Performance Control
  • We configure a variety of testing machines for this carbon steel seamless pipe and professional inspectors who have appropriate qualifications. JST production process is in accordance with PDCA comprehensive quality management system, strictly controlling the production process of the seamless steel tube for boiler and superheater. We check pipes according to customers' requirements, such as eddy current testing, magnetic particle testing, magnetic flux leakage testing, ultrasonic joint inspection and other related inspection reports for carbon steel seamless pipe.
  • Manufacturing
  • According to ASTM A210/ASME SA210 standards, the steelmaking process of this seamless steel tube uses killed steel. We also produce in accordance with the customers' specific requirements and adopt cold finishing or hot-trimming or hot finishing.
Specifications of ASTMA210/ASME SA210 Carbon Steel Seamless Pipe

1. Chemical Composition

Standard Grade Chemical Composition (%)
C Si Mn P S Cr Mo Cu Ni V
ASTM A210
ASME SA210		 A-1 ≤ 0.27 ≥ 0.10 ≤ 0.93 ≤ 0.035 ≤ 0.035 / / / / /
C ≤ 0.35 ≥ 0.10 0.29-1.06 ≤ 0.035 ≤ 0.035 / / / / /

2. Mechanical Property

Standard Grade Tensile Strength (MPa) Yield Strength (MPa) Elongation (%)
ASTM　A210
ASTM SA210		 A-1 ≥ 415 ≥ 255 ≥ 30
C ≥ 485 ≥ 275 ≥ 30

Founded in 1984, Jiangyin Changjiang Steel Tube Making Factory is a professional manufacturer of carbon steel seamless pipes in China. Our products mainly cover casing, tubing or oil pipe, line pipe, drill pipe, seamless steel tube for boiler and superheater, marine pipe, cylinder tube, hydraulic prop tube, fluid pipe, structure pipe, etc. They have passed API 5CT, API 5L, API 5DP, CCS, LR, DNV, ABS, NK, BV, GL, PED, SGS, ISO9001:2000 and ISO14001:2004 certifications. Our carbon steel seamless pipes have won widespread praise and recognition by customers.
